Infrastructure Development

RAIN’s research provides Algoma producers with solutions to barriers currently limiting the production or sale of agricultural goods. This research has identified a need for development in areas of transportation, storage, land clearing and tile drainage infrastructure.

NOHFC Regional Infrastructure Program (Tile Drainage & Land Clearing)

Since 2014, the Rural Agri-Innovation Network has been undertaking regional tile drainage and land clearing projects on Manitoulin Island and within the Algoma District.

The Northern Ontario Heritage Fund Corp. will fund 50 percent of land clearing and/or tile drainage contractor costs (including materials) to a maximum of $500 per acre. For more info on the program, download: NOHFC Funding Support for Agricultural Projects.

To date, two consortiums consisting of over 50 land owners in total have benefited from NOHFC’s Strategic Economic Infrastructure Program:

PROJECT LOCATION FUNDING RECEIVED TILE DRAINAGE (ACRES) LAND CLEARING (ACRES)
Tile Drainage Algoma $989,000 1,650 0
Tile Drainage & Land Clearing Manitoulin $976,200 1,552 75
TOTAL   $1,965,200 3,202 75

If you would like more information about this program, please contact Melissa Watson, Infrastructure Development Coordinator at (705) 942-7927 ext. 3135 or mwatson@ssmic.com.

Downloads

Producer Agreement Algoma-West Sudbury

Producer Agreement – Manitoulin Island


Identifying needs for the development of infrastructure such as agricultural drainage, the Rural Agri-Innovation Network and the Sault Ste. Marie Innovation Centre recruited Conestoga Rovers & Associates, and C.G. Trivers Ltd. to conduct an Agricultural Engineering Analysis and Develeopment strategy for drainage in the Algoma District.

What is Tile Drainage or Subsurface Drainage?

The purpose of tile drainage or subsurface drainage is to lower the water table of poorly drained fields by placing perforated drain tubes 2-12 feet beneath the soil. Modern “tile drains” are corrugated, flexible, and perforated (PE or PVC) pipelines wrapped with filter material to improve permeability and prevent the entry of soil particles. Tile drains can be installed by a landowner on their own properties, or otherwise must be done by a licensed professional.



Benefits of Tile Drainage

  • Soil surface of tiled land will warm and dry out more quickly, allowing access to the field earlier and longer;
  • Crops can develop a deeper root system even in extreme wet or dry conditions (see image below);
  • Studies have shown that crop yields and quality will improve by 20-30% when compared to those on untiled land;
  • Improves aeration in the soil and reduces the risk of soil compaction;
  • The ability to better manage water depths on farmland reduces the risk of flood.

How tile drains work

Click on image to enlarge

For more information on the environmental and economic benefits of tile drainage, see Fraser and Fleming’s literature review.

This Northern Ontario Heritage Fund Corp. funded program will subsidize 50% (to a maximum of $500 per acre) of contractor costs associated with land clearing projects.

Agricultural land clearing constitutes the removal of trees, bushes, rock piles, boulders or other natural obstructions to productive farmland. For the program purposes, land clearing activities can also entail the removal of roots, stumps, and rocks from the ground in order to establish a bed of soil that is ready for seeding or pasture. Other practices that will also qualify for this program will include clearing fence lines and overgrown pastures.
